описание:
Havoline Multi-Vehicle ATF is an ultra high performance multipurpose automatic transmission fluid formulated for use in passenger car and heavy duty truck and bus automatic transmissions. It is suitable for service fill of many transmissions manufactured by European, North American and Asian OEMs.
Havoline Multi-Vehicle ATF is formulated with premium quality severely hydroprocessed base stocks combined with an advanced additive system designed to promote oxidation and thermal stability, friction control, load- carrying ability, corrosion and wear protection. Havoline Multi-Vehicle ATF also offers protection against the formation of harmful sludge, varnish and other deposits, as well as foam.
Customer benefits
• Advanced formulation offers protection against gear, bearing and clutch wear and corrosion, helping reduce maintenance costs
• Offers robust protection against sludge, lacquer and harmful deposit formation, aiding keep-clean system performance
• Premium base stock in combination with anti oxidation additive system offers long fluid service life
• Friction modifier technology promotes smooth shifting, efficient power transfer, and anti-shudder protection
• Low temperature fluidity and rapid circulation in cold weather start-up contributes to reliable system wear protection
• Compatible with a wide range of seal elastomers helping prevent fluid loss due to seal deterioration
• Robust corrosion inhibitor performance offers reliable transmission fluid cooler protection
Applications
• Havoline Multi-Vehicle ATF is suitable for many transmissions manufactured by European, Asian and North American OEMs
• Havoline Multi-Vehicle ATF is recommended for applications that call for the former DEXRON®-III, MERCON® and Allison C-4 fluids, as well as for ZF and Voith requirements. Havoline Multi-Vehicle ATF has passed the JASO 1A standard tests for performance in Japanese vehicles. The product will offer the shifting performance and anti-shudder durability required by Japanese and Korean automakers
• In addition to the performance standards listed below, Havoline Multi-Vehicle ATF may be used as a replacement for the following fluids:
- Esso
LT 71141 Idemitsu K17
Shell ATF 3403 M-115
Texaco ATF 402
• Havoline Multi-Vehicle ATF is not suitable for a limited number of special applications. For example:
- Ford transmissions manufactured before 1977 and some pre-1982 transmissions require an M2C33-F/G fluid such as Texamatic 9330 (ATF formulated without friction modifier)
- Vehicles with continuously variable transmissions (CVTs) require special fluids
• Always check your owner’s manual to determine the proper automatic transmission fluid for your vehicle
Approvals
• Voith H55.6335.xx
• ZF TE-ML 03D
• ZF TE-ML 04D
• ZF TE-ML 14B
• ZF TE-ML 16L
• ZF TE-ML 17C
Performance
• Daimler MB 236.9
• JASO 1A
• MAN 339 Type V1
• MAN 339 Type Z2
Recommendations
• Allison C4 1
• Chrysler ATF+4
• Daimler MB 236.6
• Daimler MB 236.11
• Ford Mercon 1
• Ford Mercon V 2
• GM DEXRON-IIIH 1
• Honda ATF-Z1
• Hyundai/Kia/Mitsubishi Diamond SP-III
• Nissan MATIC-J
• Nissan MATIC-K
• Toyota Type T-III
• Toyota Type T-IV (JWS 3309)
• Volkswagen G 052 990
Typical test data |
||
Test |
Test methods |
Results |
Viscosity Grade |
|
2178 |
Appearance |
Visual |
Red |
Viscosity, Kinematic, 100°C, mm2/s |
ASTM D445 |
7.3 |
Viscosity, Kinematic, 40°C, mm2/s |
ASTM D445 |
37 |
Viscosity, Brookfield, -40°C, mPa.s |
ASTM D2983 |
18,400 |
Viscosity Index |
ASTM D2270 |
169 |
Density, 15°C, kg/l |
ASTM D1298 |
0.863 |
Flash Point COC, °C |
ASTM D92 |
198 |
Pour Point, °C |
ASTM D97 |
-53 |
