описание:
Geartex EP-C are high performance automotive gear lubricants suitable for use in applications requiring API GL- 5 performance. Formulated with mineral base stocks and highly effective additives these lubricants are available in viscosity grades SAE 80W-90 and 85W-140.
Customer benefits
• Reliable shear stability contributes to consistent viscosity and system protection throughout fluid service life
• Low temperature fluidity performance helps ensure rapid lubrication and system wear protection during cold start-up
• High performance EP protection promotes resistance to component scuffing and wear
• Robust oxidation stability helps protect against in-service oil thickening, and aids system cleanliness
• Compatible with a wide range of elastomers, assisting in fluid loss prevention though leakage
• Helps prevent components rusting and any resulting system damage
• Foam suppression optimises lubrication performance
Applications
• Geartex EP-C is designed for use in automotive hypoid drive axles, steering systems, non-synchronized transmissions and transaxles which require a fluid with API GL-5 performance
• The friction characteristics of Geartex EP-C make it unsuitable for use in synchronized manual transmissions and transaxles, and it should not be used in these applications unless a GL-5 fluid is specifically recommended
• Operating temperatures of above +100°C will lead to a significant reduction in the fluid service life. Peak operating temperatures should not exceed +120°C
• Note that Daimler axle oil specifications include a minimum viscosity requirement that is not met by Geartex EP-C 80W-90. Although Geartex EP-C 80W-90 is suitable for use in MB 235.0 applications, use Geartex EP-B 85W-90 if an approved product is required
Approvals
|
ZF |
TE-ML 16B |
80W-90 |
— |
|
ZF |
TE-ML 16D |
— |
85W-140 |
|
ZF |
TE-ML 17B |
80W-90 |
— |
|
ZF |
TE-ML 19B |
80W-90 |
— |
|
ZF |
TE-ML 21A |
80W-90 |
85W-140 |
Performance
|
API |
GL-5 |
80W-90 |
85W-140 |
|
US Military |
MIL-L-2105D |
80W-90 |
85W-140 |
|
Volvo |
97310-90 |
80W-90 |
— |
|
Volvo |
97310-91 |
— |
85W-140 |
|
ZF |
TE-ML 07A |
80W-90 1, 2 |
85W-140 1, 3 |
|
ZF |
TE-ML 08 |
80W-90 1 |
85W-140 1 |
Recommendations
|
Daimler |
MB 235.0 |
80W-90 |
— |
|
MAN |
342 Type M1 |
80W-90 |
— |
|
ZF |
TE-ML 05A |
80W-90 4 |
85W-140 4 |
|
ZF |
TE-ML 12A |
80W-90 5 |
85W-140 5 |
|
ZF |
TE-ML 19B |
— |
85W-140 6 |
1 Products meeting the necessary requirements for this specification are approved without listing
2 For outside temperatures above -26°C
3 For outside temperatures above -12°C
4 Previously approved, but ZF has changed the technical requirements for inclusion in this list
5 Obsolete specification
6 Previously approved, but SAE 85W-140 grades are no longer approved for this application.
|
Typical test data |
|||
|
Test |
Test methods |
Results |
|
|
Viscosity Grade |
|
80W-90 |
85W-140 |
|
Product Code |
|
02316 |
02317 |
|
Density, 15 °C, kg/l |
ASTM D4053 |
0.899 |
0.907 |
|
Flash Point COC, °C |
ASTM D92 |
212 |
214 |
|
Pour Point, °C |
ASTM D97 |
-33 |
-18 |
|
Viscosity, Kinematic, 100 °C, mm2/s |
ASTM D445 |
14.0 |
26.1 |
|
Viscosity, Kinematic, 40 °C, mm2/s |
ASTM D445 |
135 |
360 |
|
Viscosity Index |
ASTM D2270 |
101 |
100 |
